Molex Lite-Trap? SMT 線對板連接器系統
概述
產品亮點
類別：
線對板連接器
插配高度：
4.20 毫米
電流：
9.0A
線徑規格 AWG：
18-24 (Solid Wire)
特性和優點
Low profile (4.20 mm)
Meets needs of thin LED modules and other compact applications
User-friendly push-button latch
Ensures easy wire extraction
Dual-contact gate-style terminal design
Enables secure electrical contact and high wire-retention force
Long wire insulation design
Provides stable wire placement for additional contact assurance
Compact industry-standard PCB pattern layout
Saves space and is drop-in compatible with certain competitive products
The termination method of Molex’s Lite-Trap connector system is similar to Molex’s Wire Trap connectors, and also to certain competitive “Poke-In” type connectors.A stripped wire is inserted into the connector and pushes open a gate-style terminal that “traps” the wire.To unmate, a button-style lever on the housing top is pushed down to allow the wire to be disengaged.
With a profile height of 4.20 mm, Molex’s Lite-Trap connectors offer the lowest profile available of similar wire-removable types.Other lower-profile versions are available in the market, but these are permanent one-time connection types that do not allow wire removal.
Molex’s wire-removable Lite-Trap connector offers lower wire insertion force than similar types.It also offers a user-friendly latch that is easy for operators to engage and disengage, even without the use of a tool.These features combine to offer easy field assembly and removal if needed for trained or untrained operators.
Other features of the Lite-Trap connector include a housing design that accepts more insulation-length range than competitive designs.This provides more stable wire seating for electrical contact assurance.The dual-contact wire-trap clamp design provides further mating assurance.
1 CIRCUIT
2 個電路
